PA66 Nylon Long Leg 5A to 20A Tiny 2 ATA Blade Micro2 58V DC Micro 2 Automotive Car Auto Fuse
ATA 58V micro2 Car Fuse
Fast Acting For Rated Voltage Up To 58V DC
Rating: 5A to 20A
Body Material: Nylon with 25% Fiberglass
Cover Material: Nylon with 25% Fiberglass, Blue
Metal Material: Copper Alloy, gal.Sn
Interruption Ratings: 1000A 58VDC
Specifications
| Body Material | Nylon with 25% Fiberglass |
| Cover Material | Nylon with 25% Fiberglass, Blue |
| Metal Material | Copper Alloy, gal. Sn |
| Interruption Ratings | 1000A 58VDC |
Opening Time / Pre-arcing Time
| In | 1.1In | 1.35In | 2.0In | 3.5In | 6.0In |
| 1~20A | >100 hr | Min. | Max. | Min. | Max. | Min. | Max. | Min. | Max. |
| 0.75 s | 1800 s | 0.15 s | 30 s | 0.04 s | 0.5 s | 0.01 s | 0.1 s |
| Part Number | Amperage | Voltage(VDC) | Body Color |
| 1441 1100 200 | 1A | 58V | 0000 |
| 1441 1200 200 | 2A | 0000 |
| 1441 1300 200 | 3A | 0000 |
| 1441 1400 200 | 4A | 0000 |
| 1441 1500 200 | 5A | 0000 |
| 1441 1750 200 | 7.5A | 0000 |
| 1441 2100 200 | 10A | 0000 |
| 1441 2150 200 | 15A | 0000 |
| 1441 2200 200 | 20A | 0000 |
Contact Details:
Andy Wu
Email: andy@tianrui-fuse.com.cn
MP/Whatsapp: +86 13532772961
Wechat: HFeng0805
Skype: andywutechrich
QQ: 969828363
Our Service
1.We are manufacturer.
2. We have best quality control, Best Service and competitive Price.
3.100% QC inspection Before Shipment.
4 100% New &Original.
Delivery
Shipping: UPS / Fedex / DHL / TNT / EMS. Pls contact us directly which way your preferred.
For the Countries & Regions where EMS cannot deliver, pls choose other shipping ways.
FAQ
A.Is your parts new and original ?
Answer : Yes !Our parts could accept any kinds of testing , if there is any quality problems we will take responsible .
B.What is your warranty ?
Answer : Within 60 days after package have been received .
C.How to pay the order ?
Answer : We could accept TT , Escrow , Paypal , Western Union and Alipay .After the order have been confirmed the invoice will be sent for reference .Then make payment as the way you like , as soon as the payment have been confirmed ,we will arrange shipment within 3 days .
D.Quality problems
Answer : If there is any quality problems or questions , we could offer technical support or return service .
E.What is your lead time ?
Answer :There are no lead times for in-stock products. Most of the parts could be shipped out within 3 days after payment have been confirmed.
F.May I have a sample for testing ?
Answer :Yes ! Only to pay shipping cost ,free samples could be sent for testing .
Product Tags:
|
|
ATA 58V DC Micro 2 Blade Fuses PA66 Nylon Long Leg 20 Amp Auto Fuse Images
|
